Portable Core Drilling Rig Flexible Movement Geotechnical Drilling Equipment Hydraulic Core Drilling Rig

Name: Portable Core Drilling Rig Flexible Movement Geotechnical Drilling Equipment Hydraulic Core Drilling Rig
Brand: SANROCK
Price: 1 USD

Buy cheap Portable Core Drilling Rig Flexible Movement Geotechnical Drilling Equipment Hydraulic Core Drilling Rig product

Maximum output torque of vertical shaft : 15KN

Vertical shaft speed(4th gear) : 71,142,310,620 r/min

Model Number : SRC200

Product name : hydraulic core drilling rig

Place of Origin : Zhejiang, China

Vertical shaft travel : 450mm

Supply Ability : 5000Set/Sets per Month

Maximum feed pressure of vertical shaft : 15KN

Dimension(l*w*h) : 2700*900*1500mm

Final hole diameter : 75mm

MOQ : 1Set/Sets per Month

Delivery Time : 15-25days

Packaging Details : Nude package for machines, Wooden box package for spare parts, Or customer demand.

Application : Geological Exploration

Rated speed : 2200r/min

Usage : water well.core sample

Brand Name : SANROCK

Name : borehole drilling rig,core drilling rig

Type : Core Drilling Rig

Feature : High Drilling Efficiency,portable，Light Weight

Maximum lifting weight of vertical shaft : 25KN

Single package size : 2150×880×1560 mm

Certification : CE ISO 9001:2015

Hole dip Angle : 90-75°

Drilling Diameter : 75-325mm

Drill rod diameter : 42-60mm

Single gross weight : 760 kg

Power : 16.2KW

After-sales service provided : Online support

Payment Terms : L/C,D/A,D/P,T/T,Western Union,

Drilling Depth : 200m

Price : negotiable

Contact Now

Portable Core Drilling Rig Flexible Movement Geotechnical Drilling Equipment Hydraulic Core Drilling Rig

200m Trailer Mounted Core Drilling Rig for Geological Exploration
This compact, trailer-mounted core drilling rig is specifically designed for geological drilling to depths of up to 200 meters. Its small footprint and towable configuration enable rapid deployment across varied terrain, making it an excellent choice for mineral prospecting, geological mapping, and geotechnical sampling in remote or challenging locations.
The hydraulic core drilling rig features a powerful rotary head with variable speed and torque control, capable of penetrating a wide spectrum of rock formations. A precision hydraulic feed system ensures smooth, consistent core recovery while minimizing sample disturbance. The integrated trailer chassis is equipped with screw-type outriggers and a self-leveling mechanism for stable operation on uneven ground. Essential components such as a wireline winch, rod holder, and optional water/mud pump are included for efficient drilling operations.
Core sample drilling rig delivers reliable performance at 200-meter depths, offering an ideal balance of portability and professional-grade coring capability for geological survey projects that require frequent site changes and quick setup.

Portable Core Drilling Rig Flexible Movement Geotechnical Drilling Equipment Hydraulic Core Drilling Rig

Products Description

Brand Name:SANROCK

Product name :Core Drilling Rig

Name: Core Drilling Machine

Power Type :Diesel

Feature :High Drilling Efficiency,portable,Light Weight

Packaging Details:packing according to customer's requirement.

Model number:Diesel engine
Rated speed:2200r/min
Power:16.2KW
Borehole depth:200M
Pipe diameter:50mm
Opening diameter:75-325mm
Final hole diameter:75mm
Hole dip Angle:90-75°
Gyrator
Vertical shaft speed(4th gear):71,142,310,620 r/min
Vertical shaft travel:450mm
Maximum output torque of vertical shaft:15KN
Maximum feed pressure of vertical shaft:15KN
Maximum lifting weight of vertical shaft:25KN
Single package size:2150×880×1560 mm
Single gross weight:760 kg

Portable Core Drilling Rig Flexible Movement Geotechnical Drilling Equipment Hydraulic Core Drilling Rig
